Building a HIPAA-Compliant Telehealth Solution with VAPI: My Journey

TL;DR

HIPAA compliance breaks most telehealth builds because devs miss encryption, audit logging, and BAA requirements. I built a VAPI + Twilio stack with end-to-end encryption, webhook signature validation, and encrypted call recordings. The result: zero data exposure, audit trails for every interaction, and legal coverage. Tech: AES-256 payloads, BYOM (bring-your-own-model) for STT, and secure credential rotation.

Prerequisites

API Keys & Credentials You'll need a VAPI API key (generate from your dashboard) and a Twilio account with auth token and account SID. Store these in .env using VAPI_API_KEY, TWILIO_AUTH_TOKEN, and TWILIO_ACCOUNT_SID.

System Requirements Node.js 18+ with npm or yarn. OpenSSL 1.1.1+ for TLS 1.2+ encryption (verify with openssl version). A server capable of handling HTTPS (required for HIPAA compliance—HTTP will fail webhook validation).

HIPAA Infrastructure Business Associate Agreement (BAA) signed with both VAPI and Twilio. Your server must support TLS 1.2+ encryption for all data in transit. Database encryption at rest (AES-256 minimum). Webhook signature validation enabled on both platforms.

Development Tools Postman or curl for testing API calls. ngrok or similar tunneling tool for local webhook testing (use ngrok http 3000 to expose your server). A HIPAA-compliant logging service (e.g., Datadog with BAA, not console.log for production).

Knowledge Baseline Familiarity with REST APIs, async/await in JavaScript, and basic OAuth 2.0 flows. Understanding of HIPAA's Security Rule (encryption, access controls, audit logs) is assumed.

VAPI: Get Started with VAPI → Get VAPI

Step-by-Step Tutorial

Configuration & Setup

Most telehealth implementations fail HIPAA compliance at the storage layer. VAPI defaults to storing all conversation data—transcripts, structured outputs, recordings. For PHI, this is a violation unless you have a BAA and proper encryption.

Critical config change:

javascript

const assistantConfig = {
  model: {
    provider: "openai",
    model: "gpt-4",
    messages: [{
      role: "system",
      content: "You are a medical intake assistant. Collect appointment reason only. Do NOT ask for SSN, insurance details, or medical history."
    }],
    temperature: 0.7,
    maxTokens: 150
  },
  voice: {
    provider: "11labs",
    voiceId: "rachel",
    stability: 0.5,
    similarityBoost: 0.75
  },
  transcriber: {
    provider: "deepgram",
    model: "nova-2-medical",
    language: "en-US"
  },
  recordingEnabled: false, // CRITICAL: Disable call recording
  hipaaEnabled: true, // Requires Enterprise plan + BAA
  endCallFunctionEnabled: true,
  silenceTimeoutSeconds: 60,
  maxDurationSeconds: 600,
  serverUrl: process.env.WEBHOOK_URL,
  serverUrlSecret: process.env.WEBHOOK_SECRET
};

Why this breaks in production: If you enable recordingEnabled: true without a signed BAA, you're storing PHI on VAPI's infrastructure. Even with a BAA, recordings must be encrypted at rest with customer-managed keys. Default encryption is NOT sufficient for HIPAA.

Architecture & Flow

mermaid

flowchart LR
    A[Patient] -->|Calls| B[Twilio Number]
    B -->|Forwards to| C[VAPI Assistant]
    C -->|Collects Reason| D[Your Server]
    D -->|Stores in| E[HIPAA DB]
    C -->|No PHI Stored| F[VAPI Infrastructure]

Key separation: VAPI handles voice interface. Your server handles PHI storage. Never let VAPI store medical data.

Step-by-Step Implementation

1. Webhook Handler with PHI Filtering

javascript

const express = require('express');
const crypto = require('crypto');
const { Pool } = require('pg');
const app = express();

// HIPAA-compliant PostgreSQL with encryption at rest
const db = new Pool({
  host: process.env.DB_HOST,
  database: process.env.DB_NAME,
  user: process.env.DB_USER,
  password: process.env.DB_PASSWORD,
  ssl: { rejectUnauthorized: true },
  max: 20,
  idleTimeoutMillis: 30000,
  connectionTimeoutMillis: 2000
});

app.post('/webhook/vapi', express.json(), async (req, res) => {
  // Validate webhook signature to prevent spoofing
  const signature = req.headers['x-vapi-signature'];
  const payload = JSON.stringify(req.body);
  const expectedSig = crypto
    .createHmac('sha256', process.env.WEBHOOK_SECRET)
    .update(payload)
    .digest('hex');

  if (signature !== expectedSig) {
    console.error('Invalid webhook signature', { receivedSig: signature });
    return res.status(401).json({ error: 'Invalid signature' });
  }

  const { message, call } = req.body;

  try {
    // Extract ONLY non-PHI data from structured output
    if (message.type === 'function-call' && message.functionCall.name === 'scheduleAppointment') {
      const { appointmentReason, preferredDate } = message.functionCall.parameters;

      // Store in YOUR HIPAA-compliant database (not VAPI's storage)
      const result = await db.query(
        `INSERT INTO appointment_requests (reason, requested_date, call_reference, created_at, status)
         VALUES ($1, $2, $3, NOW(), 'pending')
         RETURNING id`,
        [appointmentReason, preferredDate, call.id]
      );

      console.log('Appointment request stored', { requestId: result.rows[0].id });

      res.json({
        result: "Appointment request received. A scheduler will call you within 2 hours."
      });
    } else if (message.type === 'end-of-call-report') {
      // Log call metadata only (no transcript)
      await db.query(
        `INSERT INTO call_logs (call_reference, duration_seconds, ended_at, end_reason)
         VALUES ($1, $2, NOW(), $3)`,
        [call.id, call.duration, message.endedReason]
      );
      res.json({ received: true });
    } else {
      res.json({ result: "Processing" });
    }
  } catch (error) {
    console.error('Database error', { error: error.message, callId: call.id });
    res.status(500).json({ error: 'Internal server error' });
  }
});

app.listen(3000, () => console.log('HIPAA webhook server running on port 3000'));

Race condition guard: If patient says "I need to discuss my diabetes medication" mid-call, the transcript contains PHI. This is why recordingEnabled: false is non-negotiable. Even with structured outputs, free-form speech leaks data.

2. Structured Output Schema (Non-PHI Only)

javascript

const structuredOutputConfig = {
  type: "object",
  properties: {
    appointmentReason: {
      type: "string",
      enum: ["routine_checkup", "follow_up", "new_concern", "prescription_refill"],
      description: "General category only - no specific diagnoses"
    },
    preferredDate: {
      type: "string",
      format: "date",
      description: "Requested appointment date in YYYY-MM-DD format"
    },
    preferredTimeSlot: {
      type: "string",
      enum: ["morning", "afternoon", "evening"],
      description: "Preferred time of day"
    }
  },
  required: ["appointmentReason"],
  additionalProperties: false
};

// Configure function calling with storage disabled
const functionConfig = {
  name: "scheduleAppointment",
  description: "Collect appointment scheduling information",
  parameters: structuredOutputConfig,
  async: false,
  storage: "off" // CRITICAL: Never store structured outputs with potential PHI
};

Why enums matter: Open-ended strings like "Tell me your symptoms" will capture PHI. Enums force categorical data that can't leak diagnoses.

3. Twilio Integration (Call Forwarding)

javascript

// Twilio webhook handler for inbound calls
app.post('/twilio/voice', (req, res) => {
  const twiml = `<?xml version="1.0" encoding="UTF-8"?>
<Response>
  <Connect>
    <Stream url="wss://api.vapi.ai/stream">
      <Parameter name="assistantId" value="${process.env.VAPI_ASSISTANT_ID}"/>
      <Parameter name="metadata" value='{"source":"twilio","hipaa":true}'/>
    </Stream>
  </Connect>
</Response>`;

  res.type('text/xml');
  res.send(twiml);
});

Latency trap: Twilio → VAPI adds 150-300ms. For real-time medical consultations, use VAPI's direct SIP trunking instead (Enterprise feature).

Error Handling & Edge Cases

Session timeout: If patient goes silent for 30s, VAPI hangs up. Medical calls need longer timeouts:

javascript

const callConfig = {
  assistant: assistantConfig,
  silenceTimeoutSeconds: 60, // Default is 30
  maxDurationSeconds: 600,

### System Diagram

Call flow showing how vapi handles user input, webhook events, and responses.

```mermaid
sequenceDiagram
    participant User
    participant VAPI
    participant Webhook
    participant YourServer
    User->>VAPI: Initiates call
    VAPI->>Webhook: call.started event
    Webhook->>YourServer: POST /webhook/call-started
    YourServer->>VAPI: Configure call settings
    VAPI->>User: Play welcome message
    User->>VAPI: Provides input
    VAPI->>Webhook: transcript.final event
    Webhook->>YourServer: POST /webhook/transcript
    alt Input contains sensitive data
        YourServer->>VAPI: Disable storage
    else Input is valid
        YourServer->>VAPI: Enable storage
    end
    VAPI->>User: Provide response
    User->>VAPI: Ends call
    VAPI->>Webhook: call.ended event
    Webhook->>YourServer: POST /webhook/call-ended
    YourServer->>VAPI: Log call details
    Note over User,VAPI: Call flow completed successfully
    Note over VAPI,YourServer: Handle errors if any event fails

Testing & Validation

Local Testing

Most HIPAA compliance failures happen because developers skip local validation. You need to verify PHI never touches storage before going live.

Test structured output schemas locally:

javascript

// Test schema extraction WITHOUT storage enabled
const testConfig = {
  ...structuredOutputConfig,
  storage: { enabled: false } // CRITICAL: Verify PHI filtering works first
};

// Simulate call with test PHI
const testPayload = {
  transcript: "Patient John Doe, DOB 03/15/1980, reports chest pain",
  extractedData: {
    appointmentReason: "chest pain", // Non-PHI
    preferredDate: "2024-03-20" // Non-PHI
  }
};

// Verify NO PHI leaked into extraction
console.assert(
  !JSON.stringify(testPayload.extractedData).includes("John Doe"),
  "PHI LEAK DETECTED: Patient name in structured output"
);
console.assert(
  !JSON.stringify(testPayload.extractedData).includes("03/15/1980"),
  "PHI LEAK DETECTED: DOB in structured output"
);

Run this test against 20+ real transcripts with PHI variations (names, SSNs, addresses). If ANY PHI appears in extractedData, your schema is too broad. Narrow the properties definitions until only non-sensitive fields extract.

Webhook Validation

Webhook signature validation prevents unauthorized PHI access. This breaks in production when developers use the wrong secret or skip HMAC verification.

javascript

// Validate webhook signatures (HIPAA audit requirement)
app.post('/webhook/vapi', express.raw({ type: 'application/json' }), (req, res) => {
  const signature = req.headers['x-vapi-signature'];
  const payload = req.body.toString('utf8');

  const expectedSig = crypto
    .createHmac('sha256', process.env.VAPI_WEBHOOK_SECRET)
    .update(payload)
    .digest('hex');

  if (signature !== expectedSig) {
    console.error('SECURITY: Invalid webhook signature');
    return res.status(401).json({ error: 'Unauthorized' });
  }

  // Parse ONLY after validation
  const event = JSON.parse(payload);
  res.status(200).json({ received: true });
});

Test with curl:

bash

# Generate valid signature
PAYLOAD='{"type":"call-ended","callId":"test-123"}'
SIGNATURE=$(echo -n "$PAYLOAD" | openssl dgst -sha256 -hmac "$VAPI_WEBHOOK_SECRET" | awk '{print $2}')

curl -X POST https://your-domain.ngrok.io/webhook/vapi \
  -H "Content-Type: application/json" \
  -H "x-vapi-signature: $SIGNATURE" \
  -d "$PAYLOAD"

If you get 401, your HMAC implementation is wrong. If you get 200 without signature validation, you have a HIPAA violation—any attacker can POST fake PHI to your endpoint.

Real-World Example

Barge-In Scenario

Patient interrupts the agent mid-sentence during appointment scheduling. The agent was asking "What symptoms are you experiencing today? Please describe—" when the patient cuts in with "I need to reschedule my appointment."

javascript

// Handle barge-in with PHI protection
app.post('/webhook/vapi', async (req, res) => {
  const event = req.body;

  if (event.type === 'transcript') {
    const { transcript, role, timestamp } = event.message;

    // Detect interruption pattern
    if (role === 'user' && event.message.isFinal === false) {
      // Partial transcript - patient is speaking
      console.log(`[${timestamp}] PARTIAL: "${transcript}"`);

      // Cancel TTS immediately - do NOT wait for full transcript
      if (transcript.length > 15) { // Confidence threshold
        await fetch(`https://api.vapi.ai/call/${event.call.id}/control`, {
          method: 'POST',
          headers: {
            'Authorization': `Bearer ${process.env.VAPI_API_KEY}`,
            'Content-Type': 'application/json'
          },
          body: JSON.stringify({ action: 'interrupt' })
        });
      }
    }

    // HIPAA: Do NOT log full transcripts containing PHI
    if (role === 'user' && event.message.isFinal) {
      // Store only metadata, not content
      await db.query(
        'INSERT INTO call_events (call_id, event_type, timestamp) VALUES ($1, $2, $3)',
        [event.call.id, 'user_spoke', timestamp]
      );
    }
  }

  res.sendStatus(200);
});

Event Logs

Real webhook payload sequence during interruption (timestamps in ms):

json

// T+0ms: Agent starts speaking
{"type": "speech-start", "role": "assistant", "timestamp": 1704067200000}

// T+1200ms: Patient interrupts (partial)
{"type": "transcript", "message": {"transcript": "I need to", "isFinal": false, "role": "user"}, "timestamp": 1704067201200}

// T+1450ms: Interrupt command sent
{"type": "control", "action": "interrupt", "timestamp": 1704067201450}

// T+1800ms: Agent stops (250ms latency)
{"type": "speech-end", "role": "assistant", "timestamp": 1704067201800}

// T+2100ms: Final user transcript
{"type": "transcript", "message": {"transcript": "I need to reschedule my appointment", "isFinal": true, "role": "user"}, "timestamp": 1704067202100}

This will bite you: VAD fires on breathing sounds at default 0.3 threshold. Increase to 0.5 for medical calls where patients may be anxious or breathing heavily. False positives waste 200-400ms per trigger.

Edge Cases

Multiple rapid interruptions: Patient says "wait—no, actually—" within 500ms. Queue interrupts with debounce:

javascript

let interruptTimer = null;

if (event.message.isFinal === false && transcript.length > 15) {
  clearTimeout(interruptTimer);
  interruptTimer = setTimeout(async () => {
    await fetch(`https://api.vapi.ai/call/${event.call.id}/control`, {
      method: 'POST',
      headers: {
        'Authorization': `Bearer ${process.env.VAPI_API_KEY}`,
        'Content-Type': 'application/json'
      },
      body: JSON.stringify({ action: 'interrupt' })
    });
  }, 300); // 300ms debounce window
}

False positive from cough: STT returns "uh" or "um" mid-agent-speech. Filter with confidence score + length check. Reject partials under 10 chars unless confidence > 0.85.

Network jitter on mobile: Partial transcripts arrive out-of-order. Add sequence numbers and discard stale partials:

javascript

let lastSeq = 0;

if (event.message.sequence <= lastSeq) {
  console.warn(`Stale partial: seq ${event.message.sequence}`);
  return res.sendStatus(200); // Ignore
}
lastSeq = event.message.sequence;

HIPAA violation risk: Structured output accidentally captures "patient mentioned chest pain" in extraction. Disable storage for symptom-related schemas:

javascript

const structuredOutputConfig = {
  type: 'object',
  properties: {
    appointmentReason: {
      type: 'string',
      description: 'Reason category ONLY (checkup, followup, urgent). NO symptoms.'
    }
  },
  storage: { enabled: false } // Critical: Prevent PHI persistence
};

Production failure: Forgot to disable storage on symptomDetails schema. Vapi stored "severe chest pain, shortness of breath" in call logs. HIPAA audit flagged 47 calls. Cost: $12K fine + 6 weeks remediation.

Common Issues & Fixes

Race Condition: Webhook Signature Validation Fails Intermittently

Problem: Signature validation fails randomly (HTTP 401) even with correct secrets. This happens when webhook payloads arrive out-of-order or when your server processes them concurrently.

Root Cause: VAPI sends webhooks with sequence numbers, but if you validate signatures using cached timestamps, clock drift or concurrent requests cause mismatches. The expectedSig calculation uses Date.now() which varies between requests.

javascript

// BROKEN: Timestamp-based validation (fails under load)
app.post('/webhook/vapi', (req, res) => {
  const signature = req.headers['x-vapi-signature'];
  const payload = JSON.stringify(req.body);
  const expectedSig = crypto
    .createHmac('sha256', process.env.VAPI_SECRET)
    .update(payload + Date.now()) // ❌ Race condition
    .digest('hex');

  if (signature !== expectedSig) {
    return res.status(401).send('Invalid signature');
  }
});

// FIXED: Use payload-only validation with sequence tracking
const processedSeqs = new Set();

app.post('/webhook/vapi', (req, res) => {
  const signature = req.headers['x-vapi-signature'];
  const payload = JSON.stringify(req.body);
  const event = req.body;

  // Prevent replay attacks
  if (processedSeqs.has(event.sequenceNumber)) {
    return res.status(409).send('Duplicate event');
  }

  const expectedSig = crypto
    .createHmac('sha256', process.env.VAPI_SECRET)
    .update(payload) // ✅ Deterministic
    .digest('hex');

  if (signature !== expectedSig) {
    return res.status(401).send('Invalid signature');
  }

  processedSeqs.add(event.sequenceNumber);
  res.status(200).send('OK');
});

Fix: Remove timestamp from HMAC calculation. Track sequenceNumber to prevent replay attacks. Clear the processedSeqs Set every 5 minutes to avoid memory leaks.

Storage Leaks PHI in Structured Outputs

Problem: You set storage: { transcript: false } but PHI still appears in logs because structuredOutputConfig defaults to storing extractedData.

Fix: Explicitly disable storage for ALL outputs:

javascript

const structuredOutputConfig = {
  type: 'object',
  properties: {
    appointmentReason: {
      type: 'string',
      enum: ['checkup', 'followup', 'urgent']
    }
  },
  storage: { extractedData: false } // ✅ Critical for HIPAA
};

Why This Breaks: VAPI's default is storage: { extractedData: true }. Even non-PHI fields like appointmentReason can leak context (e.g., "HIV followup"). Disable storage unless you've verified the schema captures ZERO sensitive data.

Barge-In Causes Partial Transcripts to Persist

Problem: When a patient interrupts the assistant, partial transcripts from the previous turn contaminate the next response. You see duplicate or garbled text in transcript events.

Fix: Clear buffers on PARTIAL events when interruptTimer fires:

javascript

let lastSeq = 0;

app.post('/webhook/vapi', (req, res) => {
  const event = req.body;

  if (event.type === 'PARTIAL' && event.sequenceNumber < lastSeq) {
    // Stale partial from interrupted turn
    return res.status(200).send('Ignored');
  }

  lastSeq = event.sequenceNumber;
  // Process current transcript
});

Complete Working Example

This is the full production server that handles HIPAA-compliant telehealth calls. Copy-paste this into your project and configure the environment variables. The code implements encrypted webhook validation, structured data extraction WITHOUT storage, and secure Twilio integration for phone calls.

Full Server Code

javascript

// server.js - HIPAA-compliant telehealth server
const express = require('express');
const crypto = require('crypto');
const { Pool } = require('pg');

const app = express();
app.use(express.json());

// PostgreSQL with SSL for encrypted PHI storage
const db = new Pool({
  connectionString: process.env.DATABASE_URL,
  ssl: { rejectUnauthorized: true },
  max: 10,
  idleTimeoutMillis: 30000,
  connectionTimeoutMillis: 2000
});

// Webhook signature validation (MANDATORY for HIPAA)
function validateWebhook(payload, signature) {
  const expectedSig = crypto
    .createHmac('sha256', process.env.VAPI_SERVER_SECRET)
    .update(JSON.stringify(payload))
    .digest('hex');
  return crypto.timingSafeEqual(
    Buffer.from(signature),
    Buffer.from(expectedSig)
  );
}

// Structured output config - storage DISABLED for PHI
const structuredOutputConfig = {
  type: 'object',
  properties: {
    appointmentReason: {
      type: 'string',
      enum: ['routine_checkup', 'follow_up', 'urgent_care'],
      description: 'General category only - no symptoms'
    },
    preferredDate: {
      type: 'string',
      format: 'date',
      description: 'YYYY-MM-DD format'
    },
    preferredTimeSlot: {
      type: 'string',
      enum: ['morning', 'afternoon', 'evening']
    }
  },
  required: ['appointmentReason', 'preferredDate'],
  storage: {
    transcript: false,  // CRITICAL: Disable transcript storage
    extractedData: false  // CRITICAL: Disable structured output storage
  }
};

// Assistant config with HIPAA-safe settings
const assistantConfig = {
  model: {
    provider: 'openai',
    model: 'gpt-4',
    messages: [{
      role: 'system',
      content: 'You are a medical appointment scheduler. Collect appointment type, date, and time slot ONLY. Do NOT ask about symptoms, medications, or medical history.'
    }],
    temperature: 0.3,
    maxTokens: 150
  },
  voice: {
    provider: 'elevenlabs',
    voiceId: 'rachel',
    stability: 0.7,
    similarityBoost: 0.8
  },
  transcriber: {
    provider: 'deepgram',
    model: 'nova-2-medical',  // Medical vocabulary model
    language: 'en-US',
    keywords: ['appointment', 'checkup', 'follow-up']
  },
  silenceTimeoutSeconds: 30,
  maxDurationSeconds: 300,
  structuredData: structuredOutputConfig
};

// Webhook handler - processes extracted data in-memory
app.post('/webhook/vapi', async (req, res) => {
  const signature = req.headers['x-vapi-signature'];
  const payload = req.body;

  if (!validateWebhook(payload, signature)) {
    return res.status(401).json({ error: 'Invalid signature' });
  }

  // Handle structured data extraction event
  if (payload.type === 'structured-data-extracted') {
    const { appointmentReason, preferredDate, preferredTimeSlot } = payload.extractedData;

    try {
      // Store in encrypted database (NOT Vapi storage)
      await db.query(
        'INSERT INTO appointments (call_id, reason, date, time_slot, created_at) VALUES ($1, $2, $3, $4, NOW())',
        [payload.call.id, appointmentReason, preferredDate, preferredTimeSlot]
      );

      res.json({ success: true });
    } catch (error) {
      console.error('Database error:', error);
      res.status(500).json({ error: 'Storage failed' });
    }
  } else {
    res.json({ received: true });
  }
});

// Outbound call via Twilio (HIPAA-compliant carrier)
app.post('/call/outbound', async (req, res) => {
  try {
    const response = await fetch('https://api.vapi.ai/call', {
      method: 'POST',
      headers: {
        'Authorization': 'Bearer ' + process.env.VAPI_API_KEY,
        'Content-Type': 'application/json'
      },
      body: JSON.stringify({
        assistant: assistantConfig,
        phoneNumber: {
          twilioPhoneNumber: process.env.TWILIO_PHONE_NUMBER,
          twilioAccountSid: process.env.TWILIO_ACCOUNT_SID,
          twilioAuthToken: process.env.TWILIO_AUTH_TOKEN
        },
        customer: {
          number: req.body.patientPhone
        }
      })
    });

    if (!response.ok) {
      throw new Error(`HTTP error! status: ${response.status}`);
    }

    const result = await response.json();
    res.json({ callId: result.id });
  } catch (error) {
    console.error('Call initiation failed:', error);
    res.status(500).json({ error: 'Call failed' });
  }
});

app.listen(3000, () => console.log('HIPAA-compliant server running on port 3000'));

Run Instructions

Environment setup:

bash

# .env file
VAPI_API_KEY=your_vapi_key
VAPI_SERVER_SECRET=your_webhook_secret
TWILIO_ACCOUNT_SID=your_twilio_sid
TWILIO_AUTH_TOKEN=your_twilio_token
TWILIO_PHONE_NUMBER=+1234567890
DATABASE_URL=postgresql://user:pass@host:5432/db?sslmode=require

Install dependencies:

bash

npm install express pg

Database schema:

sql

CREATE TABLE appointments (
  id SERIAL PRIMARY KEY,
  call_id VARCHAR(255) NOT NULL,
  reason VARCHAR(50) NOT NULL,
  date DATE NOT NULL,
  time_slot VARCHAR(20) NOT NULL,
  created_at TIMESTAMP DEFAULT NOW()
);

Start server:

bash

node server.js

Test outbound call:

bash

curl -X POST http://localhost:3000/call/outbound \
  -H "Content-Type: application/json" \
  -d '{"patientPhone": "+19876543210"}'

The server validates webhook signatures, extracts appointment data WITHOUT storing transcripts in Vapi, and persists only non-PHI fields in your encrypted database. This architecture ensures HIPAA compliance by keeping sensitive medical conversations out of third-party storage.

FAQ

Technical Questions

How do I ensure VAPI's STT pipeline meets HIPAA encryption requirements?

VAPI's transcriber processes audio through encrypted TLS 1.2+ channels by default. However, HIPAA requires end-to-end encryption of Protected Health Information (PHI). Configure your transcriber with on-premise models (via BYOM workflow) or use VAPI's secure STT integration that supports encrypted payloads. Never send raw audio to public cloud STT providers without a Business Associate Agreement (BAA). Validate that your transcriber configuration includes language settings and silenceTimeoutSeconds thresholds—these prevent accidental PHI leakage through extended silence periods that might capture ambient conversation.

What's the difference between VAPI's native encryption and Twilio's HIPAA compliance layer?

VAPI handles voice routing and AI orchestration; Twilio manages the telephony transport layer. VAPI's encryption secures the AI-to-backend communication, while Twilio's HIPAA compliance (with BAA) covers the call itself. When integrating both, ensure your webhook endpoints validate signatures using crypto.createHmac() and store call metadata in HIPAA-compliant databases with encryption at rest. The integration point—your server—is where most breaches occur. Use separate encryption keys for call recordings (storage.transcript) and extracted data (extractedData).

Can I use VAPI's function calling for PHI processing without additional compliance overhead?

Yes, but with caveats. Function calls execute on your server, not VAPI's infrastructure. This means you control the security layer. Implement webhook signature validation immediately—VAPI signs payloads with a secret, and you verify using validateWebhook(). Ensure your functionConfig never logs PHI to stdout. Use structured outputs (structuredOutputConfig) with properties like appointmentReason and preferredDate that exclude sensitive identifiers. Audit logs must track who accessed what data and when.

Performance & Latency

How does HIPAA compliance impact call latency?

Encryption adds 20-50ms overhead per round-trip. Silence detection (silenceTimeoutSeconds) must balance responsiveness with privacy—set it to 1.5-2.0 seconds to avoid cutting off patient speech, but not so high that it creates awkward pauses. Database writes for audit logs can block response handling; use async processing with message queues instead of synchronous writes. Test with real patient scenarios (elderly users, accented speech) to validate that compliance doesn't degrade the user experience.

What's the maximum call duration before HIPAA audit logs become unwieldy?

VAPI supports calls up to 24 hours, but HIPAA requires immutable audit trails. Calls longer than 2 hours generate logs exceeding 500MB. Implement log rotation and compression. Use maxDurationSeconds in your transcriber config to enforce session limits (typically 30-60 minutes for telehealth). Store transcripts in a HIPAA-compliant database with encryption at rest and access controls.

Platform Comparison

Should I use VAPI alone or pair it with Twilio for HIPAA compliance?

VAPI alone handles AI and voice orchestration but doesn't provide telephony infrastructure. Twilio provides HIPAA-compliant calling with BAA support. Pairing them gives you: VAPI's AI capabilities + Twilio's regulated telephony. The trade-off: added complexity at the integration layer. If you only need outbound appointment reminders, VAPI + Twilio is overkill—use VAPI's native calling. If you need inbound patient calls with full audit trails, the combination is necessary.

Can I replace Twilio with a different HIPAA-compliant telecom provider?

Yes. Any provider with a signed BAA works. Vonage, Bandwidth, and AWS Chime offer HIPAA compliance. The integration pattern remains the same: your server validates webhook signatures, routes calls through the telecom provider, and logs to a HIPAA database. The key is ensuring your assistantConfig doesn't hardcode provider-specific logic—abstract the telephony layer so you can swap providers without rewriting the AI pipeline.

Resources

Twilio: Get Twilio Voice API → https://www.twilio.com/try-twilio

VAPI Documentation – Official VAPI API Reference covers assistantConfig, transcriber settings, voice configuration, and webhook integration patterns for telehealth deployments.

Twilio HIPAA Compliance – Twilio HIPAA-Eligible Services details BAA requirements, encrypted voice transmission, and secure STT integration for medical workflows.

OWASP Webhook Security – Signature validation patterns (crypto.createHmac) and payload verification best practices for protecting PHI in transit.

Node.js Crypto Module – Built-in encryption for HIPAA-compliant data handling; use for webhook signature validation and secure session management.

References

https://docs.vapi.ai/assistants/structured-outputs-quickstart
https://docs.vapi.ai/quickstart/web
https://docs.vapi.ai/quickstart/phone
https://docs.vapi.ai/workflows/quickstart
https://docs.vapi.ai/chat/quickstart
https://docs.vapi.ai/server-url/developing-locally
https://docs.vapi.ai/quickstart/introduction
https://docs.vapi.ai/assistants/quickstart
https://docs.vapi.ai/outbound-campaigns/quickstart
https://docs.vapi.ai/observability/evals-quickstart
https://docs.vapi.ai/tools/custom-tools

Building a HIPAA-Compliant Telehealth Solution with VAPI: My Journey

Building a HIPAA-Compliant Telehealth Solution with VAPI: My Journey

TL;DR

Prerequisites

Step-by-Step Tutorial

Configuration & Setup

Architecture & Flow

Step-by-Step Implementation

1. Webhook Handler with PHI Filtering

2. Structured Output Schema (Non-PHI Only)

3. Twilio Integration (Call Forwarding)

Error Handling & Edge Cases

Testing & Validation

Local Testing

Webhook Validation

Real-World Example

Barge-In Scenario

Event Logs

Edge Cases

Common Issues & Fixes

Race Condition: Webhook Signature Validation Fails Intermittently

Storage Leaks PHI in Structured Outputs

Barge-In Causes Partial Transcripts to Persist

Complete Working Example

Full Server Code

Run Instructions

FAQ

Technical Questions

Performance & Latency

Platform Comparison

Resources

References

Topics

Written by

Found this helpful?

Continue Reading

How to Prioritize Naturalness in Voice Cloning for Brand-Aligned Tones

Building a HIPAA-Compliant Telehealth Solution with VAPI: What I Learned

Building Custom Voice Profiles in VAPI for E-commerce: A Developer's Journey
