// server.js - Production-grade setup
import express from 'express';
import crypto from 'crypto';

const app = express();
app.use(express.json());

// Validate environment on startup (fail fast)
const RETELL_API_KEY = process.env.RETELL_API_KEY;
const TWILIO_ACCOUNT_SID = process.env.TWILIO_ACCOUNT_SID;
const TWILIO_AUTH_TOKEN = process.env.TWILIO_AUTH_TOKEN;

if (!RETELL_API_KEY || !TWILIO_ACCOUNT_SID || !TWILIO_AUTH_TOKEN) {
  throw new Error('Missing required environment variables');
}

// Health check endpoint (monitors use this)
app.get('/health', (req, res) => {
  res.json({ status: 'ok', timestamp: Date.now() });
});

app.listen(3000, () => console.log('Server ready on port 3000'));

// createAssistant.js - Run once to get assistant_id
async function createAssistant() {
  const assistantConfig = {
    name: "Outbound Sales Agent",
    model: {
      provider: "openai",
      model: "gpt-4-turbo",
      temperature: 0.7,
      max_tokens: 500
    },
    voice: {
      provider: "elevenlabs",
      voice_id: "21m00Tcm4TlvDq8ikWAM", // Rachel voice
      speed: 1.0,
      stability: 0.5,
      similarity_boost: 0.75
    },
    transcriber: {
      provider: "deepgram",
      model: "nova-2",
      language: "en-US"
    },
    response_engine: {
      type: "retell-llm",
      llm_websocket_url: "wss://your-server.com/llm-websocket"
    }
  };

  try {
    const response = await fetch('https://api.retell.ai/v1/assistant', {
      method: 'POST',
      headers: {
        'Authorization': `Bearer ${RETELL_API_KEY}`,
        'Content-Type': 'application/json'
      },
      body: JSON.stringify(assistantConfig)
    });

    if (!response.ok) {
      const error = await response.json();
      throw new Error(`Assistant creation failed: ${error.message}`);
    }

    const assistant = await response.json();
    console.log('Assistant ID:', assistant.assistant_id);
    return assistant.assistant_id;
  } catch (error) {
    console.error('Failed to create assistant:', error);
    throw error;
  }
}

// initiateCall.js - Production call initiation
async function makeOutboundCall(toNumber, assistantId) {
  // Validate E.164 format (prevents 90% of dial failures)
  if (!toNumber.match(/^\+[1-9]\d{1,14}$/)) {
    throw new Error(`Invalid E.164 format: ${toNumber}`);
  }

  const callConfig = {
    from_number: process.env.TWILIO_FROM_NUMBER, // Your Twilio number
    to_number: toNumber,
    assistant_id: assistantId,
    metadata: {
      campaign_id: "Q1_2024_outreach",
      lead_source: "webinar_signup"
    },
    retell_llm_dynamic_variables: {
      customer_name: "John Doe",
      account_balance: "$1,234.56"
    }
  };

  try {
    const response = await fetch('https://api.retell.ai/v1/call', {
      method: 'POST',
      headers: {
        'Authorization': `Bearer ${RETELL_API_KEY}`,
        'Content-Type': 'application/json'
      },
      body: JSON.stringify(callConfig)
    });

    if (!response.ok) {
      const error = await response.json();
      // Common error codes: 401 (bad auth), 400 (invalid number), 429 (rate limit)
      throw new Error(`Call failed: ${response.status} - ${error.message}`);
    }

    const call = await response.json();
    console.log('Call initiated:', call.call_id);
    return call;
  } catch (error) {
    console.error('Call initiation error:', error);
    throw error;
  }
}

// webhookHandler.js - Secure webhook processing
app.post('/webhook/retell', async (req, res) => {
  const signature = req.headers['x-retell-signature'];
  const payload = JSON.stringify(req.body);

  // Validate webhook signature (CRITICAL for security)
  const expectedSignature = crypto
    .createHmac('sha256', process.env.RETELL_WEBHOOK_SECRET)
    .update(payload)
    .digest('hex');

  if (signature !== expectedSignature) {
    console.error('Invalid webhook signature');
    return res.status(401).send('Unauthorized');
  }

  const event = req.body;

  // Handle different event types
  switch (event.event) {
    case 'call_started':
      console.log(`Call ${event.call_id} started`);
      // Update CRM, start recording, etc.
      break;

    case 'call_ended':
      console.log(`Call ${event.call_id} ended. Duration: ${event.call_duration}s`);
      // Log to analytics, trigger follow-up workflows
      break;

    case 'call_analyzed':
      // Contains transcript, sentiment, custom analysis
      console.log('Call analysis:', event.call_analysis);
      break;

    default:
      console.log('Unknown event type:', event.event);
  }

  // ALWAYS respond 200 immediately (prevents retries)
  res.status(200).send('OK');
});

sequenceDiagram
    participant User
    participant RetellAI
    participant SpeechEngine
    participant NLPProcessor
    participant ErrorHandler
    User->>RetellAI: Initiates conversation
    RetellAI->>SpeechEngine: Capture audio
    SpeechEngine->>RetellAI: Audio stream
    RetellAI->>NLPProcessor: Send audio for transcription
    NLPProcessor->>RetellAI: Transcription text
    RetellAI->>User: Provide response
    Note over User,RetellAI: User feedback loop
    User->>RetellAI: Provides feedback
    RetellAI->>ErrorHandler: Check for errors
    ErrorHandler->>RetellAI: Error status
    alt Error detected
        RetellAI->>User: Notify error
    else No error
        RetellAI->>User: Continue interaction
    end
    User->>RetellAI: Ends conversation
    RetellAI->>SpeechEngine: Stop audio capture
    SpeechEngine->>RetellAI: Confirmation of stop

// Start ngrok tunnel (run in terminal)
// ngrok http 3000

// Update webhook URL in your call config
const callConfig = {
  agent_id: assistant.agent_id,
  metadata: {
    campaign_id: "test_001",
    environment: "development"
  },
  retell_llm_dynamic_variables: {
    customer_name: "Test User"
  },
  from_number: "+15551234567",
  to_number: "+15559876543"
};

// Test the call initiation
const response = await fetch('https://api.retell.ai/v1/call', {
  method: 'POST',
  headers: {
    'Authorization': `Bearer ${RETELL_API_KEY}`,
    'Content-Type': 'application/json'
  },
  body: JSON.stringify(callConfig)
});

if (!response.ok) {
  const error = await response.json();
  console.error('Call failed:', error.message, error.codes);
  // Common: 401 (bad API key), 400 (invalid phone format), 403 (insufficient credits)
}

const call = await response.json();
console.log('Call initiated:', call.call_id, call.status);

const crypto = require('crypto');

app.post('/webhook/retell', (req, res) => {
  const signature = req.headers['x-retell-signature'];
  const payload = JSON.stringify(req.body);

  const expectedSignature = crypto
    .createHmac('sha256', process.env.RETELL_WEBHOOK_SECRET)
    .update(payload)
    .digest('hex');

  if (signature !== expectedSignature) {
    console.error('Invalid webhook signature');
    return res.status(401).send('Unauthorized');
  }

  const event = req.body;
  console.log('Valid event:', event.type, event.call_id);

  // Process event based on type
  if (event.type === 'call_started') {
    // Initialize call state
  } else if (event.type === 'call_ended') {
    // Cleanup and log analysis
    console.log('Call analysis:', event.analysis);
  }

  res.status(200).send('OK');
});

// Production barge-in handler with buffer flush
app.post('/webhook/retell', async (req, res) => {
  const event = req.body;

  if (event.event === 'speech_started') {
    // Customer started speaking - IMMEDIATELY cancel TTS
    const callId = event.call.call_id;

    try {
      await fetch(`https://api.retell.ai/v2/stop-utterance`, {
        method: 'POST',
        headers: {
          'Authorization': `Bearer ${process.env.RETELL_API_KEY}`,
          'Content-Type': 'application/json'
        },
        body: JSON.stringify({
          call_id: callId,
          utterance_id: event.call.last_utterance_id // Critical: stop SPECIFIC utterance
        })
      });

      // Flush audio buffer to prevent stale audio playback
      console.log(`[${callId}] Barge-in detected - TTS cancelled at ${Date.now()}`);
    } catch (error) {
      console.error('Failed to cancel TTS:', error);
      // Fallback: agent will finish sentence (bad UX but won't crash)
    }
  }

  res.status(200).send();
});

// Event 1: Agent starts speaking (t=0ms)
{
  "event": "agent_start_talking",
  "call": {
    "call_id": "call_abc123",
    "last_utterance_id": "utt_xyz789"
  },
  "timestamp": 1704067200000
}

// Event 2: Customer interrupts (t=1200ms)
{
  "event": "speech_started", // THIS is your trigger
  "call": {
    "call_id": "call_abc123",
    "transcript": "" // Empty - speech detected but not transcribed yet
  },
  "timestamp": 1704067201200
}

// Event 3: Partial transcript arrives (t=1450ms)
{
  "event": "transcript",
  "call": {
    "call_id": "call_abc123",
    "transcript": "Wait what's my",
    "is_final": false
  },
  "timestamp": 1704067201450
}

// Race condition guard for multiple interruptions
let isProcessing = false;

if (event.event === 'speech_started' && !isProcessing) {
  isProcessing = true;
  await cancelTTS(event.call.call_id);

  // Reset flag after turn completes (use 'agent_stop_talking' event)
  setTimeout(() => { isProcessing = false; }, 5000); // 5s timeout fallback
}

// Server-side authentication wrapper
async function authenticatedCallRequest(callConfig) {
  if (!process.env.RETELL_API_KEY) {
    throw new Error('RETELL_API_KEY not configured');
  }

  try {
    const response = await fetch('https://api.retellai.com/v1/call', {
      method: 'POST',
      headers: {
        'Authorization': `Bearer ${process.env.RETELL_API_KEY}`,
        'Content-Type': 'application/json'
      },
      body: JSON.stringify(callConfig)
    });

    if (response.status === 401) {
      throw new Error('Invalid API key - check environment variables');
    }

    return await response.json();
  } catch (error) {
    console.error('Auth failed:', error.message);
    throw error;
  }
}

function validateE164(phoneNumber) {
  const e164Regex = /^\+[1-9]\d{1,14}$/;
  if (!e164Regex.test(phoneNumber)) {
    throw new Error(`Invalid E.164 format: ${phoneNumber}`);
  }
  return phoneNumber;
}

// Use before call creation
const callConfig = {
  from_number: validateE164('+14155551234'),
  to_number: validateE164('+16505551234'),
  assistant_id: assistant.ID
};

const activeCallIds = new Set();

async function makeOutboundCall(callConfig) {
  const callId = `${callConfig.to_number}-${Date.now()}`;

  if (activeCallIds.has(callId)) {
    throw new Error('Call already in progress');
  }

  activeCallIds.add(callId);
  isProcessing = true;

  try {
    const call = await authenticatedCallRequest(callConfig);
    return call;
  } finally {
    activeCallIds.delete(callId);
    isProcessing = false;
  }
}

const express = require('express');
const crypto = require('crypto');
const app = express();

app.use(express.json());

// Environment variables (set these in .env)
const RETELL_API_KEY = process.env.RETELL_API_KEY;
const TWILIO_ACCOUNT_SID = process.env.TWILIO_ACCOUNT_SID;
const TWILIO_AUTH_TOKEN = process.env.TWILIO_AUTH_TOKEN;
const RETELL_WEBHOOK_SECRET = process.env.RETELL_WEBHOOK_SECRET;

// E.164 validation regex
const e164Regex = /^\+[1-9]\d{1,14}$/;

function validateE164(phoneNumber) {
  if (!e164Regex.test(phoneNumber)) {
    throw new Error(`Invalid E.164 format: ${phoneNumber}. Must start with + and country code.`);
  }
  return phoneNumber;
}

// Track active calls to prevent duplicates
const activeCallIds = new Set();
let isProcessing = false;

// Create assistant with Retell AI
async function createAssistant() {
  const assistantConfig = {
    name: "Outbound Sales Agent",
    model: {
      provider: "openai",
      model: "gpt-4",
      temperature: 0.7,
      max_tokens: 150
    },
    voice: {
      provider: "elevenlabs",
      voice_id: "21m00Tcm4TlvDq8ikWAM",
      speed: 1.0,
      stability: 0.5,
      similarity_boost: 0.75
    },
    transcriber: {
      provider: "deepgram",
      language: "en-US"
    },
    response_engine: {
      type: "retell-llm",
      llm_websocket_url: "wss://your-server.com/llm-websocket"
    }
  };

  try {
    const response = await fetch('https://api.retellai.com/v1/assistant', {
      method: 'POST',
      headers: {
        'Authorization': `Bearer ${RETELL_API_KEY}`,
        'Content-Type': 'application/json'
      },
      body: JSON.stringify(assistantConfig)
    });

    if (!response.ok) {
      const error = await response.json();
      throw new Error(`Assistant creation failed: ${error.message}`);
    }

    const assistant = await response.json();
    return assistant.assistant_id;
  } catch (error) {
    console.error('Assistant creation error:', error);
    throw error;
  }
}

// Make authenticated outbound call
async function makeOutboundCall(assistantId, toNumber, fromNumber) {
  validateE164(toNumber);
  validateE164(fromNumber);

  const callConfig = {
    assistant_id: assistantId,
    from_number: fromNumber,
    to_number: toNumber,
    metadata: {
      campaign_id: "spring-2024-promo",
      lead_source: "website-form"
    },
    retell_llm_dynamic_variables: {
      customer_name: "John Doe",
      account_balance: "$1,234.56"
    }
  };

  try {
    const response = await fetch('https://api.retellai.com/v1/call', {
      method: 'POST',
      headers: {
        'Authorization': `Bearer ${RETELL_API_KEY}`,
        'Content-Type': 'application/json'
      },
      body: JSON.stringify(callConfig)
    });

    if (!response.ok) {
      const error = await response.json();
      throw new Error(`Call initiation failed: ${error.message} (status: ${response.status})`);
    }

    const call = await response.json();
    activeCallIds.add(call.call_id);
    return call;
  } catch (error) {
    console.error('Outbound call error:', error);
    throw error;
  }
}

// Webhook signature validation (prevents replay attacks)
function validateWebhookSignature(payload, signature) {
  const expectedSignature = crypto
    .createHmac('sha256', RETELL_WEBHOOK_SECRET)
    .update(JSON.stringify(payload))
    .digest('hex');

  if (signature !== expectedSignature) {
    throw new Error('Invalid webhook signature');
  }
}

// Webhook handler for call events
app.post('/webhook/retell', (req, res) => {
  const signature = req.headers['x-retell-signature'];
  const payload = req.body;

  try {
    validateWebhookSignature(payload, signature);

    const { event, call_id } = payload;

    switch (event) {
      case 'call_started':
        console.log(`Call ${call_id} started`);
        break;
      case 'call_ended':
        console.log(`Call ${call_id} ended`);
        activeCallIds.delete(call_id);
        break;
      case 'call_analyzed':
        console.log(`Call ${call_id} analysis:`, payload.analysis);
        break;
      default:
        console.log(`Unknown event: ${event}`);
    }

    res.status(200).json({ status: 'received' });
  } catch (error) {
    console.error('Webhook validation failed:', error);
    res.status(401).json({ error: 'Unauthorized' });
  }
});

// Main route to initiate outbound call
app.post('/initiate-call', async (req, res) => {
  if (isProcessing) {
    return res.status(429).json({ error: 'Call already in progress' });
  }

  isProcessing = true;

  try {
    const { to_number, from_number } = req.body;

    // Create assistant (cache this in production)
    const assistantId = await createAssistant();

    // Make outbound call
    const call = await makeOutboundCall(assistantId, to_number, from_number);

    res.status(200).json({
      status: 'initiated',
      call_id: call.call_id,
      assistant_id: assistantId
    });
  } catch (error) {
    res.status(500).json({ error: error.message });
  } finally {
    isProcessing = false;
  }
});

// Health check
app.get('/health', (req, res) => {
  res.status(200).json({
    status: 'healthy',
    active_calls: activeCallIds.size
  });
});

const PORT = process.env.PORT || 3000;
app.listen(PORT, () => {
  console.log(`Server running on port ${PORT}`);
});

RETELL_API_KEY=your_retell_api_key_here
TWILIO_ACCOUNT_SID=your_twilio_sid_here
TWILIO_AUTH_TOKEN=your_twilio_auth_token_here
RETELL_WEBHOOK_SECRET=your_webhook_secret_here
PORT=3000

npm install express dotenv

node server.js

curl -X POST http://localhost:3000/initiate-call \
  -H "Content-Type: application/json" \
  -d '{
    "to_number": "+14155551234",

## FAQ

### Technical Questions

**What authentication method does the /v1/call endpoint require?**

The /v1/call endpoint uses Bearer token authentication via the `Authorization` header. You pass your RETELL_API_KEY (obtained from the Retell dashboard) as `Authorization: Bearer ${RETELL_API_KEY}`. This is a standard OAuth 2.0 Bearer token pattern. The API validates the token on every request—if it's missing, expired, or invalid, you'll receive a 401 Unauthorized response. Store your RETELL_API_KEY in environment variables, never hardcode it.

**How do I format phone numbers for outbound calls?**

Phone numbers must be in E.164 format: a `+` prefix followed by country code and subscriber number (e.g., `+14155552671`). The validateE164 function uses the regex pattern `/^\+[1-9]\d{1,14}$/` to enforce this. Twilio requires E.164 formatting for the `from_number` and `to_number` fields in your call payload. Non-compliant numbers will fail silently or return a 400 Bad Request error.

**What's the difference between assistantId and assistant object in the call payload?**

You can reference an existing assistant by `assistantId` (a UUID string) or define an inline `assistant` object with full configuration (model, voice, transcriber). Using `assistantId` is faster for repeated calls; inline `assistant` objects are useful for dynamic configuration per call. You cannot use both simultaneously—the API will reject the request if both are present.

### Performance

**Why is my outbound call latency high?**

Latency spikes typically occur during: (1) assistant initialization (100-300ms if not cached), (2) Twilio SIP trunk provisioning (500-1500ms), (3) STT model loading on first request. Mitigate by pre-creating assistants and reusing `assistantId` instead of inline configs. Monitor webhook response times—if your server takes >5s to acknowledge the `call_started` event, Retell may timeout and retry, doubling latency.

**How many concurrent outbound calls can I make?**

This depends on your Retell plan tier and Twilio account limits. Track active calls using `activeCallIds` (a Set or Map) to prevent resource exhaustion. Each concurrent call consumes STT, TTS, and LLM tokens. Implement backpressure: if `activeCallIds.size >= MAX_CONCURRENT`, queue the request and process when a call ends.

### Platform Comparison

**Should I use Retell AI or Twilio's native voice APIs for outbound calls?**

Retell AI handles conversational logic (STT, LLM, TTS) natively; Twilio handles carrier routing and SIP trunking. Use Retell's /v1/call endpoint when you need intelligent, context-aware conversations. Use Twilio's Programmable Voice API directly if you need low-level call control (DTMF, call transfers, IVR trees) without AI. Most hybrid setups use Retell for agent override logic and Twilio for fallback PSTN routing.

**Can I override the assistant mid-call?**

Yes. Use the Agent override feature by sending a webhook event or API call to update the `assistant` configuration. This is useful for escalating to a human agent or switching conversation modes. However, the override must happen before the call enters the active conversation phase—mid-stream overrides may cause audio glitches or dropped context.

## Resources

**Retell AI Official Documentation**
- [API Reference](https://docs.retellai.com/api-references/overview) – Complete endpoint specifications, authentication methods, and request/response schemas for /v1/call, /v1/assistant, and webhook event structures.
- [Outbound Call Guide](https://docs.retellai.com/features/outbound-calls) – E.164 phone number formatting, call registration requirements, and agent override configurations.

**Twilio Integration**
- [Twilio Voice API Docs](https://www.twilio.com/docs/voice/api) – SIP URI handling, call control, and TWILIO_ACCOUNT_SID/TWILIO_AUTH_TOKEN credential setup.

**GitHub & Code Examples**
- [Retell SDK Repository](https://github.com/RetellAI/retell-sdk-js) – Production-grade Node.js examples for RETELL_API_KEY authentication and call registration workflows.
