// Environment configuration
const config = {
  vapiApiKey: process.env.VAPI_API_KEY,
  twilioAccountSid: process.env.TWILIO_ACCOUNT_SID,
  twilioAuthToken: process.env.TWILIO_AUTH_TOKEN,
  twilioPhoneNumber: process.env.TWILIO_PHONE_NUMBER,
  serverUrl: process.env.SERVER_URL // Your ngrok/production URL
};

flowchart LR
    A[Customer Calls] --> B[Twilio Number]
    B --> C[VAPI Assistant]
    C --> D[Function Call: Check Availability]
    D --> E[Your Server /webhook]
    E --> F[HVAC Scheduling DB]
    F --> E
    E --> C
    C --> A

const assistantConfig = {
  name: "HVAC Support Assistant",
  model: {
    provider: "openai",
    model: "gpt-4",
    temperature: 0.7,
    systemPrompt: `You are an HVAC service assistant. Handle:
- Emergency repairs (no heat/AC, gas leaks)
- Routine maintenance scheduling
- Service history inquiries
- Warranty questions

For emergencies, prioritize same-day dispatch. For maintenance, offer 3 available slots.
Always collect: address, issue description, preferred contact method.`
  },
  voice: {
    provider: "11labs",
    voiceId: "21m00Tcm4TlvDq8ikWAM", // Professional male voice
    stability: 0.5,
    similarityBoost: 0.75
  },
  transcriber: {
    provider: "deepgram",
    model: "nova-2",
    language: "en-US"
  },
  firstMessage: "Thanks for calling ABC HVAC. Are you experiencing an emergency, or would you like to schedule maintenance?"
};

assistantConfig.functions = [
  {
    name: "check_availability",
    description: "Check available service slots for HVAC appointments",
    parameters: {
      type: "object",
      properties: {
        serviceType: {
          type: "string",
          enum: ["emergency", "maintenance", "inspection"],
          description: "Type of service needed"
        },
        zipCode: {
          type: "string",
          description: "Customer's zip code for technician routing"
        },
        preferredDate: {
          type: "string",
          description: "ISO date string (YYYY-MM-DD)"
        }
      },
      required: ["serviceType", "zipCode"]
    }
  }
];

// YOUR server endpoint (not a VAPI API endpoint)
app.post('/webhook/vapi', async (req, res) => {
  const { message } = req.body;

  if (message.type === 'function-call' && message.functionCall.name === 'check_availability') {
    const { serviceType, zipCode, preferredDate } = message.functionCall.parameters;

    // Query your scheduling database
    const availableSlots = await db.query(`
      SELECT time_slot FROM technician_schedule
      WHERE zip_code = $1 AND service_type = $2 AND date >= $3
      LIMIT 3
    `, [zipCode, serviceType, preferredDate || new Date()]);

    return res.json({
      result: {
        slots: availableSlots.map(s => s.time_slot),
        message: serviceType === 'emergency'
          ? "We have a technician available within 2 hours."
          : `Available slots: ${availableSlots.map(s => s.time_slot).join(', ')}`
      }
    });
  }
});

graph LR
    Start[User Input]
    AudioCapture[Audio Capture]
    NoiseReduction[Noise Reduction]
    VAD[Voice Activity Detection]
    STT[Speech-to-Text]
    IntentDetection[Intent Detection]
    DialogManager[Dialog Management]
    APIIntegration[API Integration]
    ResponseGen[Response Generation]
    TTS[Text-to-Speech]
    End[User Output]
    Error[Error Handling]

    Start-->AudioCapture
    AudioCapture-->NoiseReduction
    NoiseReduction-->VAD
    VAD-->STT
    STT-->IntentDetection
    IntentDetection-->DialogManager
    DialogManager-->APIIntegration
    APIIntegration-->ResponseGen
    ResponseGen-->TTS
    TTS-->End

    VAD-->|No Voice Detected|Error
    STT-->|Transcription Error|Error
    APIIntegration-->|API Error|Error
    Error-->End

// Test webhook handler locally with ngrok
const express = require('express');
const crypto = require('crypto');
const app = express();

app.use(express.json());

app.post('/webhook/vapi', (req, res) => {
  const signature = req.headers['x-vapi-signature'];
  const payload = JSON.stringify(req.body);

  // Validate webhook signature (CRITICAL - prevents replay attacks)
  const expectedSignature = crypto
    .createHmac('sha256', process.env.VAPI_SERVER_SECRET)
    .update(payload)
    .digest('hex');

  if (signature !== expectedSignature) {
    return res.status(401).json({ error: 'Invalid signature' });
  }

  // Log function call parameters for debugging
  if (req.body.message?.type === 'function-call') {
    const { serviceType, zipCode, preferredDate } = req.body.message.functionCall.parameters;
    console.log('HVAC Request:', { serviceType, zipCode, preferredDate });

    // Simulate slot lookup (replace with real DB query)
    const result = availableSlots.find(slot =>
      slot.date === preferredDate && slot.zipCode === zipCode
    );

    return res.json({ result: result || { available: false } });
  }

  res.sendStatus(200);
});

app.listen(3000, () => console.log('Webhook server running on port 3000'));

// Handle slow operations asynchronously
app.post('/webhook/vapi', async (req, res) => {
  // Acknowledge immediately (prevents timeout)
  res.sendStatus(200);

  // Process in background
  if (req.body.message?.type === 'function-call') {
    processHVACRequest(req.body.message.functionCall.parameters)
      .catch(err => console.error('Background processing failed:', err));
  }
});

// Streaming STT handler - processes partial transcripts
app.post('/webhook/vapi', async (req, res) => {
  const payload = req.body;

  if (payload.message?.type === 'transcript' && payload.message.transcriptType === 'partial') {
    const partialText = payload.message.transcript.toLowerCase();

    // Detect interruption keywords
    if (partialText.includes('stopped') || partialText.includes('broken') || partialText.includes('not working')) {
      // Cancel current TTS immediately - don't wait for full transcript
      await fetch('https://api.vapi.ai/call/' + payload.call.id, {
        method: 'PATCH',
        headers: {
          'Authorization': 'Bearer ' + process.env.VAPI_API_KEY,
          'Content-Type': 'application/json'
        },
        body: JSON.stringify({
          assistant: {
            firstMessage: null, // Stop intro message
            model: {
              messages: [{ role: 'system', content: 'Customer has urgent AC failure. Skip intro. Ask: When did it stop working?' }]
            }
          }
        })
      });
    }
  }

  res.sendStatus(200);
});

// Production fix: Request deduplication
const processingRequests = new Map();

app.post('/webhook/vapi', async (req, res) => {
  const { call, message } = req.body;
  const requestId = `${call.id}-${message.functionCall?.name}-${Date.now()}`;

  // Guard against duplicate processing
  if (processingRequests.has(call.id)) {
    console.warn(`Duplicate request blocked: ${call.id}`);
    return res.json({ result: "Processing previous request" });
  }

  processingRequests.set(call.id, true);

  try {
    const result = await scheduleService(message.functionCall.parameters);
    return res.json({ result });
  } finally {
    // Cleanup after 5s to allow legitimate retries
    setTimeout(() => processingRequests.delete(call.id), 5000);
  }
});

const assistantConfig = {
  model: { provider: "openai", model: "gpt-4" },
  transcriber: {
    provider: "deepgram",
    language: "en",
    keywords: ["SEER", "R-22", "R-410A", "HVAC", "BTU"] // Boost recognition
  },
  firstMessage: "I can help with HVAC service. Common terms: SEER ratings, R-22 refrigerant, BTU capacity."
};

app.post('/webhook/vapi', async (req, res) => {
  const { call, message } = req.body;

  // Acknowledge immediately
  res.json({ result: "Looking up your account..." });

  // Process in background
  fetchCustomerHistory(message.functionCall.parameters.phoneNumber)
    .then(history => {
      // Send follow-up via VAPI API (not shown in docs, describe only)
      // In production: POST updated context back to active call
    });
});

// server.js - Complete HVAC Voice Bot Server
const express = require('express');
const crypto = require('crypto');
const app = express();

app.use(express.json());

// In-memory storage (replace with database in production)
const availableSlots = {
  '2024-01-15': ['09:00', '11:00', '14:00', '16:00'],
  '2024-01-16': ['10:00', '13:00', '15:00'],
  '2024-01-17': ['09:00', '12:00', '14:00', '16:00']
};

const processingRequests = new Map(); // Prevent duplicate processing

// Assistant configuration
const assistantConfig = {
  name: "HVAC Support Assistant",
  model: {
    provider: "openai",
    model: "gpt-4",
    temperature: 0.7,
    messages: [{
      role: "system",
      content: "You are an HVAC service assistant. Ask for service type, location, and preferred date. Be concise and professional."
    }]
  },
  voice: {
    provider: "11labs",
    voiceId: "21m00Tcm4TlvDq8ikWAM",
    stability: 0.5,
    similarityBoost: 0.75
  },
  transcriber: {
    provider: "deepgram",
    model: "nova-2",
    language: "en-US",
    keywords: ["HVAC", "furnace", "AC", "air conditioning", "heating", "repair", "maintenance"]
  },
  firstMessage: "Hi, this is HVAC Support. What service do you need today?",
  serverUrl: process.env.SERVER_URL || "https://your-domain.ngrok.io",
  serverUrlSecret: process.env.VAPI_SERVER_SECRET
};

// Function definitions for VAPI
const functions = [{
  name: "checkAvailability",
  description: "Check available appointment slots for HVAC service",
  parameters: {
    type: "object",
    properties: {
      serviceType: {
        type: "string",
        enum: ["repair", "maintenance", "installation", "emergency"],
        description: "Type of HVAC service needed"
      },
      zipCode: {
        type: "string",
        description: "Customer's ZIP code"
      },
      preferredDate: {
        type: "string",
        description: "Preferred date in YYYY-MM-DD format"
      }
    },
    required: ["serviceType", "zipCode", "preferredDate"]
  }
}];

// Webhook signature validation
function validateWebhookSignature(payload, signature) {
  const secret = process.env.VAPI_SERVER_SECRET;
  if (!secret) {
    console.error('VAPI_SERVER_SECRET not configured');
    return false;
  }

  const expectedSignature = crypto
    .createHmac('sha256', secret)
    .update(JSON.stringify(payload))
    .digest('hex');

  return crypto.timingSafeEqual(
    Buffer.from(signature),
    Buffer.from(expectedSignature)
  );
}

// Main webhook handler
app.post('/webhook/vapi', async (req, res) => {
  const signature = req.headers['x-vapi-signature'];
  const payload = req.body;

  // Validate webhook signature
  if (!validateWebhookSignature(payload, signature)) {
    console.error('Invalid webhook signature');
    return res.status(401).json({ error: 'Unauthorized' });
  }

  // Prevent duplicate processing
  const requestId = payload.message?.id || `${Date.now()}-${Math.random()}`;
  if (processingRequests.has(requestId)) {
    return res.status(200).json({ status: 'already_processing' });
  }
  processingRequests.set(requestId, true);
  setTimeout(() => processingRequests.delete(requestId), 30000); // Cleanup after 30s

  try {
    const { type, call, message } = payload;

    // Handle function calls
    if (type === 'function-call' && message?.functionCall) {
      const { name, parameters } = message.functionCall;

      if (name === 'checkAvailability') {
        const { serviceType, zipCode, preferredDate } = parameters;

        // Validate service area (example: only serve 90210-90299)
        const zipNum = parseInt(zipCode);
        if (zipNum < 90210 || zipNum > 90299) {
          return res.json({
            result: {
              success: false,
              message: `Sorry, we don't service the ${zipCode} area yet. We currently serve ZIP codes 90210-90299.`
            }
          });
        }

        // Check availability
        const slots = availableSlots[preferredDate];
        if (!slots || slots.length === 0) {
          return res.json({
            result: {
              success: false,
              message: `No slots available on ${preferredDate}. Would you like to try ${Object.keys(availableSlots)[0]}?`
            }
          });
        }

        // Return available slots
        return res.json({
          result: {
            success: true,
            serviceType,
            date: preferredDate,
            availableSlots: slots,
            message: `We have ${slots.length} slots available on ${preferredDate}: ${slots.join(', ')}. Which time works best?`
          }
        });
      }
    }

    // Handle partial transcripts (for barge-in detection)
    if (type === 'transcript' && message?.transcriptType === 'partial') {
      const partialText = message.transcript.toLowerCase();

      // Detect urgent keywords
      if (partialText.includes('emergency') || partialText.includes('urgent')) {
        console.log(`[URGENT] Detected emergency keyword in call ${call.id}`);
        // Trigger priority routing (implement your logic here)
      }
    }

    // Handle call status updates
    if (type === 'status-update') {
      console.log(`Call ${call.id} status: ${payload.status}`);

      if (payload.status === 'ended') {
        // Cleanup session data
        processingRequests.delete(call.id);
        console.log(`Call ${call.id} ended. Duration: ${call.duration}s`);
      }
    }

    res.status(200).json({ received: true });

  } catch (error) {
    console.error('Webhook processing error:', error);
    processingRequests.delete(requestId);
    res.status(500).json({ error: 'Internal server error' });
  }
});

// Health check endpoint
app.get('/health', (req, res) => {
  res.json({
    status: 'healthy',
    timestamp: new Date().toISOString(),
    activeRequests: processingRequests.size
  });
});

const PORT = process.env.PORT || 3000;
app.listen(PORT, () => {
  console.log(`HVAC Voice Bot server running on port ${PORT}`);
  console.log(`Webhook URL: ${process.env.SERVER_URL}/webhook/vapi`);
});

npm install express crypto

export VAPI_SERVER_SECRET="your_webhook_secret_from_vapi_dashboard"
export SERVER_URL="https://your-domain.ngrok.io"
export PORT=3000

node server.js

## FAQ

### Technical Questions

**How do I connect VAPI to Twilio for inbound HVAC calls?**

VAPI integrates with Twilio via SIP trunking. Configure your Twilio phone number to route inbound calls to VAPI's SIP endpoint, then set up your `assistantConfig` with the appropriate model, voice, and transcriber settings. VAPI handles the voice AI logic while Twilio manages the telephony layer. You'll need your Twilio Account SID, Auth Token, and a dedicated SIP trunk endpoint. The connection is bidirectional—VAPI can also initiate outbound calls through Twilio for appointment confirmations.

**What's the difference between using VAPI's native function calling versus building a custom proxy?**

Native function calling lets you define `functions` directly in your `assistantConfig` with parameters like `serviceType`, `zipCode`, and `preferredDate`. VAPI handles the LLM reasoning and invokes your webhook automatically. A custom proxy means you build middleware that intercepts all VAPI requests and responses, giving you control over prompt engineering, request validation, and response transformation. Native is faster (lower latency); custom proxy is more flexible but adds complexity. For HVAC scheduling, native function calling is sufficient unless you need advanced prompt engineering or multi-step orchestration.

**How do I validate webhook signatures from VAPI?**

Use HMAC-SHA256 validation. VAPI sends a `X-Signature` header with each webhook. Extract the signature, reconstruct the payload hash using your `secret`, and compare using `validateWebhookSignature()`. If signatures don't match, reject the request immediately. This prevents spoofed webhook calls that could corrupt your scheduling database.

### Performance

**What latency should I expect for HVAC appointment scheduling?**

End-to-end latency typically breaks down as: STT processing (200-400ms), LLM inference (500-1500ms), function execution (100-300ms), TTS generation (300-800ms). Total: 1.1-3.0 seconds from user speech to bot response. Network jitter on mobile adds 100-200ms. For HVAC scheduling, this is acceptable—customers expect natural conversation pauses. If latency exceeds 3 seconds consistently, check your function execution time; database queries for `availableSlots` should complete in <200ms.

**How many concurrent calls can a single VAPI instance handle?**

VAPI scales horizontally. A single assistant configuration can handle hundreds of concurrent calls, but your backend (the webhook handler for scheduling) is the bottleneck. If you're querying a database for `availableSlots`, ensure your database connection pool supports concurrent requests. For HVAC businesses with <50 concurrent calls, a standard Node.js Express server with 10-20 database connections is sufficient. Monitor webhook response times; if they exceed 5 seconds, implement async processing with job queues.

### Platform Comparison

**Should I use VAPI or build voice AI directly with Twilio?**

Twilio's Voice API requires you to build STT, LLM integration, and TTS orchestration yourself. VAPI abstracts this complexity—you define your `assistantConfig` once, and VAPI handles the entire voice pipeline. VAPI is faster to deploy (days vs. weeks) and cheaper at scale because it optimizes model selection and caching. Twilio is better if you need deep telephony control (call transfer, IVR trees, DTMF). For HVAC scheduling, VAPI wins on time-to-market and cost.

**Can I use VAPI with other phone providers besides Twilio?**

Yes. VAPI supports multiple carriers via SIP trunking. You can use Twilio, Bandwidth, Vonage, or any SIP-compliant provider. The integration method is identical—route inbound calls to VAPI's SIP endpoint, configure your `assistantConfig`, and handle webhooks. Switching providers requires only updating your SIP trunk configuration; your VAPI code remains unchanged.

## Resources

**VAPI**: Get Started with VAPI → [https://vapi.ai/?aff=misal](https://vapi.ai/?aff=misal)

**VAPI Documentation:** [Official VAPI API Reference](https://docs.vapi.ai) – Complete endpoint specs, assistant configuration schemas, webhook event payloads, and voice provider integrations (ElevenLabs, Google, Azure).

**Twilio SIP Trunking:** [Twilio SIP Trunks Guide](https://www.twilio.com/docs/sip-trunking) – Configure inbound/outbound call routing, number management, and failover strategies for production HVAC call centers.

**GitHub Reference:** [VAPI + Twilio Integration Examples](https://github.com/VapiAI) – Sample implementations for webhook signature validation, function calling patterns, and session state management.

**Prompt Engineering for HVAC:** OpenAI's [Prompt Engineering Guide](https://platform.openai.com/docs/guides/prompt-engineering) – Techniques for structuring system prompts to handle service scheduling, availability queries, and escalation logic.

## References

1. https://docs.vapi.ai/quickstart/introduction
2. https://docs.vapi.ai/assistants
3. https://docs.vapi.ai/quickstart/phone
4. https://docs.vapi.ai/workflows/quickstart
5. https://docs.vapi.ai/quickstart/web
6. https://docs.vapi.ai/chat/quickstart
7. https://docs.vapi.ai/
8. https://docs.vapi.ai/tools/custom-tools
9. https://docs.vapi.ai/server-url
10. https://docs.vapi.ai/outbound-campaigns/quickstart
11. https://docs.vapi.ai/assistants/quickstart
